Fowler Sylvac PS16 V2 3-Points Measuring bench

Measuring bench similar to the PS16 V2 bench, but equipped with a table and anvils assembly allowing very small
shallow internal diameters to be measured at 3 points, thanks to an electronic calculation function.
• Calibration using 2 rings supplied with the bench
• Table with fine height adjustment up to 3 mm with mini digital indicator for precise movement control
• Available in 5 versions :
– 808-1335: version for measuring internal diameters 0.8 to 1.3 mm
– 808-1336: execution for measuring internal diameters 1.3 to 2.5 mm
– 808-1337: execution for measuring internal diameters 2.5 to 4 mm
– 808-1338: execution for measuring internal diameters 4 to 8 mm
– 808-1339: execution for measuring internal diameters 8 to 12.5 mm

Included: Instrument according to technical specifications
Lithium battery CR2477 included
Adapter for Lithium battery CR2032
Instruction manual
Calibration certificate
Table and anvils according to technical specification
Mini indicator and 2 setting rings included
Dust cover
