Mahr Indicating Snap Gage MaraMeter M 301P – x With Lifting Lever Less Indicator 8mm mount

$1.00

Mahr Indicating Snap Gage For rapid measurements of cylindrical parts such as shafts, bolts and spindles for thickness and length measurements. avaliable with 8mm or 3/8″ indicator mount/ no indicator included

• Patented “Channel Lock” design assures precise parallel anvil surfaces throughout the full 25 mm / 1“ range of adjustment.
• All Series 300P Snap Gages are fully adjustable with positive position locking at any point within the range.
• 0.50 mm / .020“ Movement of sensitive contact.
• Snap Gages available over a wide range of sizes, styles, and readout configurations.
• Large 15.5 mm / .61“ square tungsten carbide anvils provide flat, parallel, working surfaces ensuring precision.
• Indicator can be rotated to read from front or rear of the gage.
• All adjustments accomplished using a single hex wrench (furnished).
• Scope of delivery: Allen key

2003150 Base/Bench Stand for 300P or 1000P style Snap Gage BA– 26
2204644 Bench stand for AGD style 3 disc masters up to 127mm / 5“ BA– 71
2232441 Heavier force spring for M-300P & 300P-xM SP– 118
2232478 Lighter force spring for M-300P & 300P-xM SP– 192
2202272 Plain anvil (lower), left (option) AL– 1755
2202273 Plain anvil (upper), left (option) AL– 1756
2202274 Plain anvil (lower), right (option) AL– 1757
2202275 Plain anvil (lower), right (option) AL– 1758
2202276 Plain anvil (lower), middle (option) AL– 1759
2202277 Plain anvil (lower), middle (option) AL– 1760
