Mitutoyo Linear Height LH-600E / EG Height Gage- 2D Measurement PROMO

$7,120.00$7,550.00

Mitutuyo Linear Height offers the best-in-class accuracy. Achieved by using a high-accuracy scale unit and high-accuracy guiding mechanism manufactured in Mitutoyo’s dedicated scale plant. Displacement accuracy when measuring a height of 600mm: 1.7 μm. Measuring range: 0 – 38 / 0 – 972mm  slider stroke: 24 / 600mm. Model: 518-351A-21 LH-600E and 518-352A-21 LH-600EG with power grip.

Limited time offer:On promo  – Plus Complimentary Accredited
Calibration (A2LA 0750.01) and Shipping*

PROMO 027 AND PROMO 028

Clear

Mitutoyo Linear Height LH-600E Height Gage Features:

• Excellent accuracy of (1.1+0.6L/600)μm with 0.1μm/0.5μm resolution/repeatability.
• Perpendicularity (frontal) of 5μm and straightness of 4μm are guaranteed.
• Pneumatic full/semi-floating system allows adjustment of air-cushion height.
• Basic statistical functions  provided.  RS-232C / USB data output
• One-key operation for running a semi-automatic measurement.
• Data entry from a Digimatic tool.USB, RS232

Model: 518-351A-21 LH-600E and 518-352A-21 LH-600EG with power grip



Available Options

item Product Number
518-351A-21 LH-600E #518-351A-21PROMO027
515-352A-21 LH-600EG Power grip model #518-352A-21 PROMO028

Mitutoyo Linear Height LH-600E/EG Height Gage:

  • 2D Measurement
  • Measuring range : 0 – 38 / 0 – 972mm
  • Slider stroke: 24 / 600mm
  • Resolution: 0.0001 / 0.001 / 0.01 / 0.1mm or (switchable)
    0.0001 / 0.001 / 0.01 / 0.1mm / .000001 / .00001 / .0001 / .001
  • Accuracy at 20°C: Indication accuracy *1 (1.1 + 0.6L/600)μm, L = Measured length (mm)
  • Repeatability Plane :*1 0.4μm (2σ), Hole: 0.9μm (2σ
  • Perpendicularity*2  (forward and backward)  5μm (after compensation)
  • Straightness *2(forward and backward) 4μm (mechanical accuracy).
  • Floating method: Full / semi-floating with built-in air compressor
  • Display:TFT LCD (color)
  • LH-600EG with power grip

Download the Mitutoyo LH-600E Linear Height Gage information using the link below:

Mitutoyo Linear Height LH-600E_EG – Series 518 Electronic 2DHeight Gage
