Shimpo FGS-100E Motorized Force Test Stand


The Shimpo FGS-100E motorized stands have a capacity rating of 110 lbs (50 kgf) in either fast [0.78-23.60 in/min(20-600 mm/min)] movement operation or slow speed [0.23-7.00 in/min (6-180 mm/min)] operation models. When connected to a Shimpo FGV Force Gage, the gages programmable overload setting is communicated to the test stand, allowing the stand to stop at the overload set point and prevent potential damage to the gage's sensor

Read More

Shimpo FGS-100E Motorized Force Test Stand Features:

  • Simplified 7 button key-pad with emergency safety stop provides a user-friendly platform that does not require extensive training
  • Compatibility with nearly all manufacturers’ force gauges enables flexibility in testing applications
  • Field selectable inches/min or mm/min allows user preference or to change as needed per test requirement
  • Large 100-230 VAC power capability provides flexible installation; eliminates power transformer
  • Quick-adjust manual upper and lower limits eliminates set-up time for the next test
  • Compact, modular design reduces weight, footprint and cost of stand
  • Stroke 15.75 in (400 mm)

Shimpo FGS-100E Motorized Force Test Stand:

  • Capacity: 112.4 lbf (500N, 50kgf)
  • Movement Speed: FGS-100E-L (6-180 mm/min) FGS-100E-H (200-600 mm/min)
  • Speed Accuracy: +/-5%
  • Stroke: 15.75 in (400mm)
  • Display: LCD 3 Digits indicates movement speed, Operation Mode
  • Temperature Range: 32-113F No Condensation

Download the Shimpo FGS-100E Motorized Force Test Stand product information using the link below:

Shimpo FGS-100E Motorized Force Test Stand
