Non-Contact Gaging for Precision Turned Parts
Non-Contact Gaging for measuring Precision Turned PartsS. Measure shafts, measure ODs, Measure threads, etc
Read More
Inspection Systems
InGage Discovery
Stand Alone Video Metrology System
> Accurate within 0.0001"
> Choose from seven different image sizes.
> Automated part blow off sorting.
> Three inspection attachments available, with more to come!
InGage Inspection Software
Software Analyzing Part's Back-lit Profiles
> Integrates with sorting systems.
> Powerful feature extracting tools.
> Highly configurable.
> Large library of tips and instructions.
Gemini Dual Cam 360
> Inspect large turned parts:
- OAL: Up to 1.5"
- OD: 2.5" to 4.5"
> Complete profile inspection:
- Ability to measure part OOR and other warping
- 100% inspection for defects
Custom Capabilities
Automated Go/No-Go Gages - 100% Production Sorting
> Sort similar parts automatically by OAL.
> Reject missing features due to broken tools or CNC failures.
> Inspect for wraparound chips in grooves.
> What is your inspection task?
Customized Sensor Manufacturer
Not all QC inspections are feasible with off the shelf sensors. We provide both novel and elegant solutions for your most challenging inspection needs.
Orion194 Flat Platen Sorter
> Sorts turned, screw-machined, molded, & stamped parts
> Inspection and sorting performance:
- Accuracy: Within 0.0001"
- Inspection Rate: 10 Parts Per Second Max
> Additional Inspection:
- Top Camera: Inspect OD, ID, and runout
- Optical Sensor: Detect hidden feature presence
- Smart Camera: Trainable detection
Orion197 Tilted Platen Sorter
> Sorts long cylindrical parts, like pins, spindles, and screws.
> Inspection and sorting performance:
- Accuracy: Within 0.0001"
- Inspection Rate: 10 Parts Per Second Max
> Tilts to accommodate parts with heads, flanges, or tapers.
> Offset head to measure part as it rotates.
> External trigger to measure OAL of long parts.
Eclipse Track Sorter
The Eclipse: Track Sorter uses a pneumatically controlled escapement to release parts down a track one at a time for inspection and sorting. The base unit analyzes a single snapshot of the part's profile as the part passes down the track. Two variants of the system allow for complete exterior profile and/or ID/OD inspection. The Eclipse platform is a great sorting solution for moderately sized, 1" - 2" OD, turned parts and tube cutoffs. Providing precise measurements of features such as:
Diameters & Heights.
Chamfers & Rounds.
Taper & Angles.
Circularity & Straightness.
Threads.
> Sorts turned parts, pins, and tube cutoffs
- OD: 1.25" - 2.00"
> Multiple designs to fit your inspection requirements.
Orion Platen Sorter
> Sorts turned parts, pins, and tube cutoffs that are:
- OAL: Up to 1.125"
- OD: Up to 0.187"
> Inspection and sorting performance:
- Accuracy: Within 0.00005"
- Inspection Rate: 10 Parts Per Second Max
